Met deze controller kan je vier verschillende motoren tegelijk besturen en komt met z’n eigen GPIO-bibliotheek waardoor het ontzettend makkelijk is verschillende motoren onafhankelijk van elkaar te besturen. En het ziet er nog mooi uit ook, wat wil je nog meer? De controller is zo gemaakt dat deze op alle verschillende Raspberry Pi-modellen past, ook de Zero.
MotoZero features:
Kit includes:
- MotoZero PCB
- 40-pin GPIO header
- 2x Motor driver chips
- 2x Motor driver sockets
- 5x Terminal blocks
- 1x capacitor
Further Details:
- Control 4 motors independently in both forwards and reverse
- Control with basic GPIO ‘on/off’ code, or use the excellent GPIO Zero library
- Terminals break out the motor outputs to the edge of the board, ideal for wheeled and tracked robots
- Robust chunky terminal blocks for solid connections
- Raw motoring looks with piston print and retro motor font. The board layout is symmetrical where possible to further enhance its appearance.
- Pi Zero sized, although will fit all 40pin Raspberry Pi models
- Simply power your Pi the usual way (via the micro-USB connection using a plug, power bank or similar) and then add battery power for the motors.
- Built-in flyback diodes within the controller chips, which prevent damage from motor ‘flyback’ voltage spikes.
- Electroless Nickel Immersion Gold (ENIG) PCB for excellent soldered contacts, oxidisation prevention and looks
- Kit form – enjoy building your own motor controller!
- Full user guide with assembly, code examples and motor selection advice. (available HERE!)
NOTE:
- The MotoZero comes in kit form and requires soldering assembly.
- Please ensure you read the provided manual before assembly and usage.
- Special attention should be given to the motor power wire polarity
